Long ago, in the mists of time, it was a symbol of the navigation star for the sailors. Have you heard about the wind rose No, it’s not a flower growing in the flower bed.
#Wind rose diagram of cavite how to
The wind coverage can be calculated by summing up all the percentages. How to draw a wind rose step by step 2 0. The runway should be thus oriented along the direction indicated by the central line. With the centre of wind rose rotate the tracing paper and place it in such a position that the sum of all the values indicating the duration of wind within the two outer parallel lines is the maximum. Place the transparent paper strip over the wind rose diagram in such a way that the central line passes through the centre of the diagram. This distance is measured with the same scale with which the wind rose diagram is drawn the permissible cross wind component is 25kph. The procedure for determining the orientation of runway from this type of wind rose is described below.ĭraw three equi spaced parallel lines on a transparent paper strip in such a way that the distance between the two near by parallel lines is equal to the permissible cross wind component. The values entered in each segment represent the percentage of time in a year during which the wind having a particular intensity blows from the respective direction.
Each circle represents the wind intensity to some scale. the wind data as in the previous type is used for this case. Type – II : this type of wind rose is illustrated in fig. This type of wind rose does not account for the effect of cross wind component. The total percentage of the time therefore comes to 57.0 + 13.5 = 70.5. If deviation of wind direction up to 22.5º + 11.25ºfrom their direction of runway is thus along NS direction of landing and take off is permissible the percentage of time in a year during which runway can safely be used for landing and take off will be obtained by summing the percentages of time along NNW, N, NNE, SSE, S and SSW directions. The best direction of runway is usually along the direction of the longest lone on wind rose diagram. All plotted points are then joined by straight lines. The values are plotted along the north direction in fig similarly other values are also plotted along the respective directions. the radial lines indicate the wind direction and each circle represents the duration of wind. Type – I: This type of wind rose is illustrated in fig. Showing direction duration and intensity of wind. Wind rose diagrams can be plotted in two typesġ. The wind data should usually be collected for a period of at least 5 years and preferably of 10 years so as to obtain an average data with sufficient accuracy. Wind rose: the wind data direction duration and intensity are graphically represented by a diagram called wind rose.
